2870032 engine mounting
Unit2870032Detail
|
Unit2870032Detail |
|||||||
|
Num |
Hot Num |
Diagram No. |
Name |
Quantity |
Vertion |
Disuse Time |
Unit Code |
|
6 |
1 |
752W96210-0070 |
Front rubber mounting |
002 |
2870032 |
||
|
18 |
2 |
ZQ1851240TF6 |
Hexagon bolts with flange |
004 |
2870032 |
||
|
19 |
3 |
ZQ1851255TF6 |
Hexagon bolts with flange |
004 |
2870032 |
||
|
1 |
4 |
752W97488-0001 |
Block |
002 |
2870032 |
||
|
23 |
5 |
ZQ32516T13F6 |
Hexagon flange nuts with teeth |
002 |
2870032 |
||
|
21 |
6 |
WG9925590266 |
Stud |
002 |
2870032 |
||
|
24 |
7 |
752W96210-0080 |
Rear rubber mounting |
002 |
2870032 |
||
|
36 |
8 |
ZQ1851280TF6 |
Hexagon bolts with flange |
004 |
2870032 |
||
|
38 |
9 |
ZQ32312T13F6 |
Hexagon nuts with flange |
008 |
2870032 |
||
|
48 |
10 |
ZQ1811460TF6 |
Hexagon flange bolts with teeth |
004 |
2870032 |
||
|
39 |
11 |
752W41501-0009 |
Left bracket |
001 |
2870032 |
||
|
47 |
12 |
ZQ1811645TF6 |
Hexagon flange bolts with teeth |
008 |
2870032 |
||
|
37 |
13 |
ZQ1851255TF6 |
Hexagon bolts with flange |
004 |
2870032 |
||
|
43 |
14 |
752W41501-0010 |
Right bracket |
001 |
2870032 |
||
|
20 |
15 |
ZQ32312T13F6 |
Hexagon nuts with flange |
004 |
2870032 |
||
