8364490 Dual drive axle brake chamber section
Unit8364490Detail
|
Unit8364490Detail |
|||||||
|
Num |
Hot Num |
Diagram No. |
Name |
Quantity |
Vertion |
Disuse Time |
Unit Code |
|
60 |
1 |
WG9000360900 |
Spring brake chamber |
002 |
8364490 |
||
|
62 |
2 |
WG9000360901 |
Spring brake chamber |
002 |
8364490 |
||
|
2 |
3 |
Q5101440 |
Pin |
004 |
8364490 |
||
|
3 |
4 |
Q40114 |
Washer |
004 |
8364490 |
||
|
4 |
5 |
Q5004030 |
Pin |
004 |
8364490 |
||
|
15 |
6 |
190003179785 |
Plastic tube |
019 |
8364490 |
||
|
27 |
7 |
WG9000361007 |
Gasket |
012 |
8364490 |
||
|
29 |
8 |
WG9000361008 |
Clip |
012 |
8364490 |
||
|
31 |
9 |
WG9000361009 |
Nut |
012 |
8364490 |
||
|
33 |
10 |
WG9000361204 |
Nozzle |
007 |
8364490 |
||
|
35 |
11 |
WG9000361310 |
Nozzle |
004 |
8364490 |
||
|
37 |
12 |
WG9000361406 |
Nozzle |
007 |
8364490 |
||
|
39 |
13 |
WG9525360104 |
bracket |
002 |
8364490 |
||
|
41 |
14 |
ZQ1840830 |
Hexagon bolts with flange |
002 |
8364490 |
||
|
42 |
15 |
ZQ32008 |
Hexagon nuts with flange |
002 |
8364490 |
||
|
43 |
16 |
WG9725360088 |
Cable binder |
004 |
8364490 |
||
|
49 |
17 |
190003171356 |
Cable binder |
006 |
8364490 |
||
|
45 |
18 |
190003171393 |
Cable binder |
016 |
8364490 |
||
|
46 |
19 |
WG9100360134 |
Spacer |
012 |
8364490 |
||
|
50 |
20 |
WG9000361001 |
Gasket |
003 |
8364490 |
||
|
52 |
21 |
WG9000361002 |
Clip |
003 |
8364490 |
||
|
54 |
22 |
WG9000361003 |
Nut |
003 |
8364490 |
||
|
56 |
23 |
WG9000361107 |
Nozzle |
002 |
8364490 |
||
|
58 |
24 |
WG9000361207 |
Nozzle |
001 |
8364490 |
||
