2300085 Fuel tank system(500L)
Unit2300085Detail
|
Unit2300085Detail |
|||||||
|
Num |
Hot Num |
Diagram No. |
Name |
Quantity |
Vertion |
Disuse Time |
Unit Code |
|
1 |
1 |
WG9925550060 |
tank bracket |
004 |
2300085 |
||
|
14 |
2 |
ZQ1811440TF6 |
Hexagon flange bolts with teeth |
016 |
2300085 |
||
|
18 |
3 |
WG9925550062 |
base for strap |
004 |
2300085 |
||
|
16 |
4 |
WG9925550061 |
strap |
004 |
2300085 |
||
|
20 |
5 |
810W97461-0014 |
PIN F SPANNBAND |
004 |
2300085 |
||
|
26 |
6 |
WG9925550065 |
CYLINDER SCREW |
004 |
2300085 |
||
|
24 |
7 |
WG9925550064 |
pin |
004 |
2300085 |
||
|
31 |
8 |
WG9925550063 |
base for bracket |
004 |
2300085 |
||
|
30 |
9 |
Q5004025 |
Pin |
004 |
2300085 |
||
|
28 |
10 |
Q5101675 |
Pin |
004 |
2300085 |
||
|
29 |
11 |
Q40116 |
Washer |
004 |
2300085 |
||
|
13 |
12 |
ZQ1811460TF6 |
Hexagon flange bolts with teeth |
016 |
2300085 |
||
|
3 |
13 |
WG9925550093 |
Bracket |
004 |
2300085 |
||
|
15 |
14 |
ZQ32514T13F6 |
Hexagon flange nuts with teeth |
032 |
2300085 |
||
|
5 |
15 |
WG9725543317 |
Plate |
004 |
2300085 |
||
|
9 |
16 |
WG9925360859 |
Plate |
004 |
2300085 |
||
